• (10) cup holders
• Cigarette lighter
• Color-keyed floor carpeting
• Electrochromic rearview mirror
• Glove Box
• Homelink universal garage door opener
• Overhead console
• Pwr adjustable pedals w/memory
• Pwr windows
• Rear floor heat ducts
• Rear window defroster
• Reversible cargo mat
• SecuriLock Passive anti-theft system
• Speed control
• Tilt steering column

• 3.73 rear axle ratio
• 4-wheel anti-lock braking system
• 4-wheel drive
• Front stabilizer bar
• Pwr 4-wheel disc brakes
• Pwr steering
• Rear stabilizer bar

• 4-wheel anti-lock braking system
• Child-proof rear door locks
• Driver & front passenger airbags

6.0L TURBO-DIESEL V8 "POWER STROKE" ENGINE

• (STD)

• Running Boards
• Towing Pkg
• V8; Turbo Diesel; 6.0L
• Automatic
• 4WD
• Air Conditioning; Rear
• AM/FM Stereo
• CD/MP3 (Single Disc)
• Dual Air Bags
• Third Row Seat
• Oversized Premium Wheels 20
• Air Conditioning
• Cassette
• Cruise Control
• Dual Power Seats
• Power Door Locks
• Power Windows
• Tilt Wheel
• ABS (4-Wheel)
• Power Steering

• Vehicle
• Rear Door Type: Tri-Panel
• Mileage
• EPA Fuel Economy Est - City (MPG): N/A
• EPA Fuel Economy Est - Hwy (MPG): N/A
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 750
• Cold Cranking Amps @ 0° F (2nd): 750
• Maximum Alternator Capacity (amps): 130
• Maximum Alternator Watts: 1950
• Cooling System
• Total Cooling System Capacity (qts): 29.6
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3800
• Gross Axle Wt Rating - Rear (lbs): 5240
• Curb Weight - Front (lbs): 4062
• Curb Weight - Rear (lbs): 3626
• Gross Vehicle Weight Rating Cap (lbs): 9200
• Gross Combined Wt Rating (lbs): 20000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 11000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1100
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): N/A
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): N/A
• Suspension
• Suspension Type - Front: Single-Stage Leaf
• Suspension Type - Rear: Single-Stage Leaf
• Spring Capacity - Front (lbs): 3800
• Spring Capacity - Rear (lbs): 5240
• Axle Type - Front: Dana 50 Monobeam
• Axle Type - Rear: Ford Std & Lim Slip
• Axle Capacity - Front (lbs): 5200
• Axle Capacity - Rear (lbs): 7000
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Stabilizer Bar Diameter - Front (in): 1.42
• Brakes
• Brake Type: Power
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.13 x - TBD -
• Rear Brake Rotor Diam x Thickness (in): 13.20 x - TBD -
• Tires
• Front Tire Order Code: T4T
• Rear Tire Order Code: T4T
• Spare Tire Order Code: T4T
• Front Tire Size: LT265/75R16D
• Rear Tire Size: LT265/75R16D
• Spare Tire Size: LT265/75R16D
• Front Tire Capacity (lbs): 3000
• Rear Tire Capacity (lbs): 3000
• Spare Tire Capacity (lbs): 3000
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 16 x 7.0
• Rear Wheel Size (in): 16 x 7.0
• Spare Wheel Size (in): 16 x 7.0
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Power
• Steering Ratio (:1), On Center: 17.0
• Turning Diameter - Curb to Curb (ft): 50.4
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder w/BlockerBeam
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 44
• Fuel Tank Location: Aft-of-axle
• Exterior Dimensions
• Wheelbase (in): 137.1
• Length, Overall w/rear bumper (in): 226.7
• Width, Max w/o mirrors (in): 79.9
• Height, Overall (in): 80.2
• Overhang, Front (in): 37.4
• Overhang, Rear w/bumper (in): 52.3
• Ground to Top of Load Floor (in): - TBD -
• Ground Clearance, Front (in): - TBD -
• Ground Clearance, Rear (in): 8.1
• Rear Door Opening Height (in): 38.1
• Rear Door Opening Width (in): 55.8
• Step Up Height - Front (in): - TBD -
• Step Up Height - Side (in): - TBD -
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Seat 1 (in): 100.9
• Cargo Area Length @ Floor to Seat 2 (in): 64.0
• Cargo Area Length @ Floor to Seat 3 (in): - TBD -
• Cargo Area Width @ Beltline (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): 52.2
• Cargo Box (Area) Height (in): - TBD -
• Cargo Volume to Seat 1 (ft³): 146.4
• Cargo Volume to Seat 2 (ft³): 100.7
• Cargo Volume to Seat 3 (ft³): 48.0
• Interior Dimensions
• Passenger Capacity: 8
• Front Head Room (in): 41.0
• Front Leg Room (in): 42.3
• Front Shoulder Room (in): 68.3
• Front Hip Room (in): 67.5
• Second Head Room (in): 41.1
• Second Leg Room (in): 40.5
• Second Shoulder Room (in): 67.0
• Second Hip Room (in): 66.9
• Third Head Room (in): 38.6
• Third Leg Room (in): 39.0
• Third Shoulder Room (in): 64.9
• Third Hip Room (in): 52.5
• Summary
• Vehicle Name: Ford Excursion
• Body Style: 4 door
• Body Code: 137" WB
